EVAL-ADP5588
SOFTWARE INSTALLATION
Installation of the LabVIEW_Runtime_Engine.exe file and
the ADP5588 GUI is required before using the ADP5588
demonstration board.
ADP5588 EVALUATION INSTALLATION
To run these installations, do the following:
1.
Insert the ADP5588 evaluation CD and run the
ADP5588 Setup.exe file. When the screen in Figure 4
appears, click Next >.
Figure 4. ADP5588 Evaluation Software Setup
2.
When the screen in Figure 5 appears, click Yes to accept
the license agreement.
Figure 5. Analog Devices Evaluation Software License Agreement
3.
When the screen in Figure 6 appears, click Next > to install
the files to the default destination folder or browse to
choose a different destination.
4.
When the screen in Figure 7 appears, click Next > to
continue with installation.
5.
When the screen in Figure 8 appears, click Next > to add
the program icons in the default program folder.
6.
When the program installation has been completed, click
Finish to complete the installation (see Figure 9).
Rev. 0 | Page 4 of 20
Figure 6. Choose Destination Location
Figure 7. Setup Type
Figure 8. Select Program Folder
