DataView™ LI55 Level Controller
|
Push Buttons
DataView™ has four buttons on the right side of the front panel. These are
the buttons you will use to set up and configure the controller.
Menu
Used to enter or exit the configuration mode, view settings or
access advanced features.
Right
Used to move to the next digit during digit or decimal point
configuration; or to reset the max/min readings or other
parameter/function assigned through the User menu.
Up
Used to scroll through the menus, decimal point or to change the
value of a digit; or to display the max/min readings or other
parameter/function assigned through the User menu.
Enter
Used to access a menu or accept a setting (changes are only
saved after this is pressed); or to acknowledge relays or other
parameters/function assigned through the User menu.
