Endress+Hauser Fieldbus levelflex M FMP 40 Operating Instructions Manual page 79

Levelflex M FMP 40 with Foundation Fieldbus
Endress+Hauser
Isolated tie down
for 4mm rope probe
for 6mm rope probe
If a rope probe has to be fixed and a
secure grounded mounting is not
possible, we recommend using the
insulating sleeve made of PEEK-GF30 with
accompanying DIN 580 eye-bolt made of
stainless steel.
Max. process temp. 150 °C.
Due to the risk of electrostatic charge, the
insulating sleeve is not suitable for use in
hazardous areas.
In these cases the fixing must be reliably
grounded (see page 23).
Service adapter FXA 193
For communication with ToF Tool via the display connector. (Bestell-Nr.: 50095566).
Commuwin II
Operating software for intelligent instruments.
Order - No.
52014249
52014250
8 Accessories
Reliable, isolated mounting
Insulating
sleeve
eye-bolt
D = 20 mm at
D
M8 DIN 580 for 4 mm rope
D = 25 mm at
M10 DIN 580 for 6 mm rope
79
