3 Mounting
F12 housing
ca. 86
reference point of
measurement
rope probe
rope:
Ø 4 mm/
or
Ø 6 mm/0.24"
Ø 22/0.87" (on 4 mm/
Ø 30/1.18" (on 6 mm/0.24" rope)
12
3.3

Installation Conditions

3.3.1 Dimensions
65 78
ENDRESS+HAUSER
Levelflex-M
85
option:
distance sleeve
4 x Ø 8,5
Ø 60,3
Ø 76
Threaded connection
G ¾ (¾ BSP)
or ¾ NPT
SW 50
0.16"
internal thread:
M14 on 4 mm/0.16" rope
M20 on 6 mm/0.24" rope
0.16" rope)
Fig. 2 Dimensions Levelflex M FMP 40
Levelflex M FMP 40 with Foundation Fieldbus
68
88
Ø 76
Threaded connection
G 1 ½ (1 ½BSP)
or 1 ½ NPT
SW 60
rod probe
Ø 6/0.24" (on ¾" thread)
Ø 16/0.63" (on 1½" thread
or flange)
T12 housing
94
65 78
ENDRESS+HAUSER
Levelflex-M
85
option:
remote electronic
Flange DN 40...200
or equivalent
Ø 60
Ø 67,8
Probe rods in Alloy C22
consist of 1 piece
(can not be dismantled)
coax probe
Ø 21,3/0.84" (on ¾" thread)
Ø 42,4/1.67" (on 1½" thread
or flange)
