Endress+Hauser Fieldbus levelflex M FMP 40 Operating Instructions Manual page 2

Brief operating instructions
Brief operating instructions
KA 189F/00/a2/03.02
52012501
000
Contrast:
measured value
- + E
Group
selection
00 002
basic setup tank
properties
+
01 - standard
safety settings - aluminium tank
- plastic tank
- bypass/pipe
- coax-probe
- concrete
wall
03 030
length end of
adjustment probe
- free
04
- tie down
linearisation
isolated
05
- tie down
extended calibr.
gnd.
092
09
language
display
0E 09A
envelope curve plot settings
- envel. curve
- substracted signal
- mapping
- 0A0
0A
present
diagnostics
error
0C
system
parameters
Note!
This operating manual explains the installation and initial start-up for the level transmitter measuring device. All
functions that are required for a typical measuring task are taken into account here.
In addition, the Levelflex M provides many other functions that are not included in this operating manual, such as
optimising the measuring point and converting the measured values.
An overview of all device functions can be found on page 94.
The operating manual BA 245F/00/en provides an extensive description of all device functions – Description of the
device functions for Levelflex M, which can also be found on the enclosed CD-ROM.
2
Levelflex M - Brief operating instructions
+ or +
- +
003 004 005
medium process empty
property cond. calibr.
- unknown - standard input E
- 1.4 ... 1.6 - fast (see sketch)
- 1.6 ... 1.9 change
- 1.9 ... 2.5
- slow
- 2.5 ... 4
change
- 4 ... 7
- test: no filter
- > 7
031 032 033
probe probe probe
length length
If shortened
please enter probe length here.
... ...
09B
recording
curve
- single curve
- cyclic
0A1 0A3
previous reset
error
(333 = reset customer parameters)
Levelflex M FMP 40 with Foundation Fieldbus
E
E
006 008 051
full dist./ check
calibr. meas value distance
input F D and L are
(see sketch) displayed
reference point of
034
measurement
determine
length
threaded
connection
¾ or 1 ½ BSP
(G ¾ or G ½) 1
¾ or 1½ NPT :
reference point of
measurement
min.level
0A4
unlock ... ...
parameter
= 100: unlocked
≠
100: locked
008
E
dist./
meas value
052 053
range of start
mapping mapping
confirm
suggestion
or specify
range
UB
E
LN
F
LB
UB = upper blocking distance
L B = lower bllocking distance
LN = probe lenght
52012501
Endress+Hauser
