UG-791

EVALUATION BOARD HARDWARE

The evaluation board requires an SDP-S motherboard to
program the device. The SDP-S board is not included and must
be purchased separately. The
shown in Figure 5 to Figure 9. The top layer and assembly layout
are shown in Figure 10.

POWER SUPPLIES

The evaluation board is powered via one external supply, 5 V
connected as described in the Quick Start Guide section.

INPUT SIGNALS

The LO input pin and the Rx input pins on the
contain a dc bias voltage; the inputs must be ac-coupled to the
evaluation board.
EV-ADF5904SD2Z schematics are
ADF5904

OUTPUT SIGNALS

The baseband outputs from the
voltages and are available on the J3 to J11 output SMAs.
Table 1. Baseband Output Mapping
Rx Input
RF1IN
RF2IN
RF3IN
RF4IN

DEFAULT OPERATION

All components necessary for
on the board.
Rev. 0 | Page 4 of 14
EV-ADF5904SD2Z User Guide
ADF5904 contain dc bias
Baseband Outputs
J3, J4
J6, J7
J8, J9
J10, J11
ADF5904 operation are inserted
