Evaluation Board User Guide

EVALUATION BOARD HARDWARE

TERMINAL BLOCK FUNCTIONS

Table 1. Link Functions
Link No. Default Location
LK1 Out
LK2 Out
LK3 In
LK4 Out
LK5 In
LK6 A
Function
Option to remove external conditioning
Option to remove external conditioning
On-board, 16 MHz crystal connection, connects to Y2
SMB connected external clock
Connects 5 V from USB to ADP3303
AVDD and DVDD power supply connector
Rev. 0 | Page 3 of 28
UG-364
