Default Configuration - Analog Devices ADSP-21160 EZ-KIT Lite Manual

• Universal 7V DC power supply
• USB 2.0 cable
If any item is missing, contact the vendor where you purchased your
EZ-KIT Lite or contact Analog Devices, Inc.

Default Configuration

The EZ-KIT Lite evaluation system contains ESD (electrostatic discharge)
sensitive devices. Electrostatic charges readily accumulate on the human
body and equipment and can discharge without detection. Permanent dam-
age may occur on devices subjected to high-energy discharges. Proper ESD
precautions are recommended to avoid performance degradation or loss of
functionality. Store unused EZ-KIT Lite boards in the protective shipping
package.
The ADSP-21160 EZ-KIT Lite board is designed to run outside your per-
sonal computer as a stand-alone unit. You do not have to open your
computer case.
To connect the EZ-KIT Lite board:
1. Remove the EZ-KIT Lite board from the package. Be careful when
handling the board to avoid the discharge of static electricity,
which may damage some components.
2. Figure 1-1
tor locations, and LEDs used in installation. Confirm that your
board is set up in the default configuration before moving to the
next step.
