Access to the ADSP-21160 processor from a personal computer (PC) is
achieved through a USB port or an optional JTAG emulator. The USB
interface provides unrestricted access to the ADSP-21160 processor and
the evaluation board peripherals. Analog Devices JTAG emulators offer
faster communication between the host PC and target hardware. Analog
Devices carries a wide range of in-circuit emulation products. To learn
more about Analog Devices emulators and processor development tools,
go to
http://www.analog.com/dsp/tools/
The ADSP-21160 EZ-KIT Lite provides example programs to demon-
strate the capabilities of the evaluation board.
The ADSP-21160 EZ-KIT Lite installation is part of the Visu-
alDSP++ installation. The EZ-KIT Lite is a licensed product that
offers an unrestricted evaluation license for the first 90 days. For
details about evaluation license restrictions after the 90 days, refer
to "Evaluation License Restrictions" on page
ADSP-21160 EZ-KIT Lite provides example programs to demonstrate the
capabilities of the evaluation board.
The board features:
• Analog Devices ADSP-21160 processor
• ADSP-21160M processor:
• Switch-configurable boot mode
• Analog Devices AD1881A 48 kHz AC'97 SoundMAX
Jumper selectable line-in or mic-in 3.5 mm stereo jack
Line-out 3.5 mm stereo jack
• USB debugging interface
x
www.BDTIC.com/ADI
2.5V core voltage
80 MHz core clock speed
ADSP-21160 EZ-KIT Lite Evaluation System Manual
.
1-7.
®
codec
