• SBSRAM
512 Kb (64K x 32-bits x 2-chips)
• Flash memory
512 Kb (512K x 8-bits)
• Interface connectors
14-pin emulator connector for JTAG interface
SPORT0
Two link port connectors
Expansion interface connectors (not populated)
• General-purpose IO
3 push buttons connected to processor IRQs
3 LEDs connected to processor flags
The EZ-KIT Lite board has two types of external memory: flash memory
and SBSRAM. The flash memory can store user-specified boot code. By
configuring the boot mode switch (
ory, the board can run as a stand-alone unit. For information about the
external memory, see
is interfaced to an audio codec, facilitating development of audio
SPORT0
signal processing applications.
nector for communication with other serial devices. For information
about , see
SPORT0
Additionally, the EZ-KIT Lite board provides access to most of the pro-
cessor's peripheral ports on populated expansion interface connectors. For
information about the expansion interface, see
page 2-3.
ADSP-21160 EZ-KIT Lite Evaluation System Manual
www.BDTIC.com/ADI
connectors
SW1
"Memory Map" on page
SPORT0
"SPORT0 Audio Interface" on page
) and programming the flash mem-
1-7.
also connects to an off-board con-
2-4.
"External Port" on
