Installation and Session Startup
6. The Select Platform page of the wizard appears on the screen.
Ensure that the selected platform is ADSP-21160 EZ-KIT Lite via
Debug Agent. Specify your own Session name for your session or
accept the default name.
The session name can be a string of any length; although, the box
displays approximately 32 characters. The session name can
include space characters. If you do not specify a session name,
VisualDSP++ creates a session name by combining the name of the
selected platform with the selected processor. The only way to
change a session name later is to delete the session and to open a
new session.
Click Next.
7. The Finish page of the wizard appears on the screen. The page dis-
plays your selections. Check the selections. If you are not satisfied,
click Back to make changes; otherwise, click Finish. VisualDSP++
creates the new session and connects to the EZ-KIT Lite. Once
connected, the main window's title is changed to include the ses-
sion name set in step 6.
To disconnect from a session, click the disconnect button
or select Session –>Disconnect from Target.
To delete a session, select Session –> Session List. Select the ses-
sion name from the list and click Delete. Click OK.
