SPORT0 Connector (P11)
links to a 20-pin connector. The connector pinout can be found in
SPORT0
"ADSP-21160 EZ-KIT Lite Schematic" on page
Part Description
20-position AMPMODU system 50
receptacle (
)
P11
20-position AMPMODU system 20
connector
20-position AMPMODU system 20
connector (w/o lock)
Flexible film contacts (20 per con-
nector)
Straight-through assembly with lock-
ing connector on each end
ADSP-21160 EZ-KIT Lite Evaluation System Manual
www.BDTIC.com/ADI
ADSP-21160 EZ-KIT Lite Hardware
Manufacturer
TYCO
Mating Connectors
AMP
AMP
AMP
Mating Assembly
GOPHER
ELECTRONICS
B-1.
Part Number
5-104069-1
2-487937-0
2-487938-0
487547-1
DRFFC10X7RHU-RHU5
2-15
