Intermec EasyCoder PL4 User Manual page 31

Note: If the printer times out, sending a print request
through the Bluetooth connection will not turn the printer
on. Make sure the printer is on before sending your print
request.
To print labels from a Bluetooth-enabled device
1 Create a label file with a .LBL extension, and load it on your
device. You can use Intermec PLUS to create your label file.
For help, see the online help.
2 Load the Bluetooth print utility for your processor on your
device:
These utilities are on the CD that came with your printer.
For help loading the utilities, see the device's manual.
3
Turn on the printer.
4
Using either Intermec PLUS or CPL, set Bluetooth
authentication On or Off. When you set Bluetooth
authentication to On, the passkey is created using an
algorithm based on the friendly name.
5 On the device, find the Bluetooth COM port setting for the
device. For example, to find the COM port on a 700 Series
Mobile computer, select My Bluetooth Device and then
COM Ports.
6 Search for the printer and establish a connection. For help,
see the device's manual.
7
Open the Bluetooth print utility on your device.
8
On the Print Utility screen, make sure the serial port matches
the port the Bluetooth connection is using.
9
From File Name, select the label file you loaded.
10
Click Print (1). The printer prints the label.
EasyCoder PL4 Printer User's Guide
Processor Bluetooth Print Utility
ARM BTPrintUtilityARM.exe
MIPS BTPrintUtilityMIPS.exe
SH3 BTPrintUtilitySH3.exe
31
