7
Rotate the latch assembly until it locks in place.
8
Turn on the printer or press the Feed button if the printer is
already on. The printer advances the media.
Tear-Off mode
Media
cover
The printer advances the media to the next label, if printing
labels. If you are printing on continuous media, the printer will
advance a short strip of media and will then be ready for
printing.
To switch from Self-Strip mode to Tear-Off mode
1 Turn off the printer.
2 Press the latch release button on the side of the printer. The
latch assembly flips open automatically.
3 Pull the self-strip bar slightly forward and then push it down.
20
Self-Strip mode
Media
cover
Latch
PL4U044.eps
assembly
EasyCoder PL4 Printer User's Guide
Latch
assembly
