To print a configuration label
1
Turn the printer off. Load the media compartment with
continuous media (media with no black marks printed on the
back).
2 Press and hold the Feed button.
3 Press and release the Power button and keep the Feed button
pressed. When printing starts, release the Feed button.
The printer prints a line of interlocking "x" characters to make
sure all elements of the printhead are working, prints out the
version of software loaded in the printer, and then prints two
reports.
The first report indicates model, firmware version, serial
number, baud rate, and other printer information. The second
report prints out more detailed information on the printer's
configuration and parameter settings. If no second report
appears, there is no application loaded.
The Wireless Communications report appears if the printer has
a Bluetooth radio or 802.11b radio option. If no radio options
are installed, the Wireless Communications Section consists of a
blank line.
The Label section shown in the second report reports the
maximum size label that can be printed, based on a printer
resolution of 8 dots per mm (203 dots per inch or dpi).
XXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXX
Intermec PL4
CHK: FFFF
HTSE7940 /18
Testing Memory...
Memory tested and OK
Baud Rate: 19200 BPS
In-activity Timeout: 120 Secs
Low battery Shut-down: 170
End of report.
Example of first report
EasyCoder PL4 Printer User's Guide
V79.40 12/23/02
Printhead Test
23
