Advanced Features
1. Specifying
Complex Bar
Codes
Intermec EasyCoder 301 Direct Protocol 2.0 – Programmer's Guide Ed. 3
Complex 2-dimensional bar or dot codes, e.g. PDF417, require many
specifying parameters. Therefore, there is a complex command that
allows all bar code parameters to be specified within a single com-
mand. This command can also be used for one-dimensional bar
codes (see chapter 4.4).
BARSET[#<start parameter>,]["<bar code name>"[,<ratio wide bars>
[,<ratio narrow bars>[,<magnification>[,<height> [,<security level>
[,<aspect ratio height>[,<aspect ratio width>[,<no. of rows>[,<no. of columns>
[,<truncate flag>]]]]]]]]]]]
<start parameter>
<bar code name>
<ratio wide bars>
<ratio narrow bars> specifies ratio wide/narrow bars
<magnification>
<height>
<security level>
<aspect height ratio> only used in PDF417 and Maxicode
<aspect height width> only used in PDF417 and Maxicode
<no. of rows>
<no. of columns>
<truncate flag>
specifies first parameter in the command
(default 1)
specifies bar code
(default "INT2OF5")
specifies ratio wide/narrow bars
(default 3)
(default 1)
specifies magnification
(default 2)
specifies height of bars in dots
(default 100)
only used in PDF417 and Maxicode
(default 2)
(default 1)
(default 2)
only used in PDF417 and Maxicode
(default 0)
only used in PDF417 and Maxicode
(default 0)
only used in PDF417 and Maxicode
(default 0)
