3 Setting up the M5200x software
Section 3.1: Prerequisites to setting up M5200x software

3.1.1: System requirements

3.1.2: Prerequisite software requirements

S. No. Prerequisite software name (click to navigate)
1 Keysight IO Libraries Suite 2018 (version 18.1.23218 or
later)
2 M9046A PXIe Chassis Drivers
3 Xilinx Vivado Design Suite (2017.3 or later)
4* Python 64-bit version 3.7.x** or greater
5* (optional) Any C# / .NET compiler
6* (optional) Any C / C++ compiler
*Install this programming interface only if it meets your requirements.
** See the section "Instructions for Python users".
48
• Windows 10 (x64 bit)
Table 8
Prior to installing any other software/drivers, Keysight recommends
NOTE
installing the IO Libraries Suite whose IO Control Bundle comprises of
several elements that support the module drivers.
General installation steps for prerequisite software
Perform these steps for installing the software in the sequence shown in
Table 8.
1 On the Technical Support page, click the "Download" button and save
the installer.
2 Run the downloaded installer.
Software to be installed prior to M5200x SW
License (Free / Procured)
Free
Free
Refer to PathWave FPGA Customer Documentation for
installation and licensing information
-
-
-
M5200A PXIe Digitizer Modules Startup Guide
