1 Overview on M5200A PXIe Digitizer Modules
Section 1.3: About products supported with M5200A modules
Required equipment
PXIe RF AWG modules
PXIe Downconverter modules
PXIe LVDS Digital IO modules
System Sync modules
Baseband AWG modules
PXIe Chassis: High-Power, 18-slot, 24 GB/s
Controller options (use one of the following options)
PXIe High-Performance Embedded Controller
External Controller*
Other accessories
PXIe 5-channel Source / Measure Unit, 100 pA
PXIe 5-channel Precision Source/Measure Unit,
500 kSa/s, 10 pA, 30 V, 500 mA
PXIe System Modules and Cable Interface
PCIe High-Performance Host Adapter
PXI Network Analyzers
Infiniium UXR-Series Oscilloscope: 16 GHz, 4 Channels
18
You require the following (recommended) Keysight products to achieve
precision and control when performing measurements. Visit the
corresponding product pages on
to the respective documentation to understand how to use these
modules/products.
Table 3 List of supported equipment
Recommended Part number(s)
M5300A
M5201A
M5302A
M9032A / M9033A
M3201A / M3202A
M9046A
M9037A
(recommended) HP Z8 1FZ80UT#ABA 2.2 GHz Intel Xeon Silver 4114
10-Core (G4 Workstation)
M9614A
M9615A
M902xA
M9049A
M980xA-series
UXR0164A
* You may use any External Controller of your choice. Keysight recommends using the HP
Z8 G4 Workstation to scale up your system for multi-chassis operations.
www.keysight.com to procure and refer
M5200A PXIe Digitizer Modules Startup Guide
