1 Overview on M5200A PXIe Digitizer Modules
Characteristics
Sampling rate
Resolution
Input impedance
Coupling
Bandwidth
Input voltage full-scale range
RMS noise (at nominal full-scale range)
Effective Number of Bits (ENOB)
Memory Depth
Spurious free dynamic range (SFDR) (50% Full-Scale)
Spurious free dynamic range (SFDR) (80% Full-Scale)
Supported PXIe Chassis
16
The key specifications of the M5200A module are listed in
other characteristics of the M5200A PXIe Digitizer modules, refer to the
M5000 Series High-Performance PXI System Datasheet.
Table 2 Key specifications of the M5200A High-speed PXIe Digitizer module
Value / Range
4.8 GSa/s
12-bit
50 Ohm
DC
DC-2 GHz
900 mV pk-pk (module default gain setting)
< 800 uV
8
1 GSa/Ch
65 dBc
65 dBc up to 1 GHz
40 dBc up to 2 GHz
M9046A
The input and output flow in the M5200A High-speed PXIe Digitizer is
shown in Figure 2. It has a System Link I/O connector synchronization and
sequencing, four bi-directional SMB I/Os, four Channels with single-ended
analog input SMA connectors, and two connectors for 2.4 GHz clkout and
2.4 GHz clkin for coherent frequency response.
