G Charge Summary - Circontrol Master-Slave Instruction Manual

Master/Slave Instruction Manual
G
1
2
3
4
5
1- Language button: pressing over this button it is possible to change the
HMI language.
2- Process instructions: different instructions can be displayed.
3- Energy charged: total energy charged at the end of the charging session.
4- Stop reason: It shows why the charging session has been stopped.
5- Exit button: It has to be pressed in order to finish the charging session.
After pressing, the HMI screen will go back to the "identification screen".
6- Recharge time: total recharging time at the end of the charging session.
7- Information button: pressing over this button you can get information
about the charging session, per example the "reason for stopping" or
another one.
18
Charge summary
7
6
