Master/Slave Instruction Manual
10
DATA GENERAL SPECIFICATIONS
Light beacon
Enclosure rating
Enclosure material
Enclosure door
Net weight
Dimensions (W x H x D)
Connectors (optional)
Power supply
Input voltage
Frequency
Meter
Operating temperature
Operating temperature with
Low Temperature Kit (optional)
Storage temperature
Operating humidity
Safety protection
Overcurrent protection
Overvoltage protection (optional)
86
RGB Colour indicator
IP54 / IK10
Aluminium & ABS
Frontal key locked door
Post: 55 kg
Wallbox Small: 25 kg
Wallbox Larger: 30 kg
Post: 450 x 1550 x 290 mm
Wallbox Small: 450 x 600 x 290 mm
Wallbox Larger: 450 x 850 x 290 mm
Shutter Type 2 Socket
Type 1 Cable
Type 2 Cable
1P+N+PE / 3P+N+PE
230VAC+/- 10% / 400VAC+/-10%
50Hz / 60Hz
MID Class 1 - EN50470-3
-5ºC to +45ºC
-30ºC to +45ºC
-20ºC to +60ºC
5% to 95% Non-condensing
RCD Type A (30mA) / Type B (optional)
MCB (curve C)
Transient surge protector IEC 61643-1
(Class II)
