Master/Slave Instruction Manual
Value
Slave charger model
Charger Name
Use auto-generated
names
IP Address
MAC Address
Perform IP address
assigment
Plug A Name
Plug B Name
42
List of Slave Charge Point models.
*NOTE: Select it carefully according to the model described on
the label.
Allows to specify the name of the charger.
*NOTE: this name only serves as a label, it does not affect the
correct operation of the equipment.
YES: 'Charger Name' assigned by default.
NO: 'Charger Name' can be edited manually.
IP address of the Slave Charge Point
MAC address of the Slave Charge Point
YES: when clicking the 'Save' button on the bottom of the web-
page, the desired IP address is assigned to the Slave Charge
Point with the MAC address specified.
NO: when clicking the 'Save' button on the bottom of the web-
page, the Slave Charge Point with the IP address specified is
added to the list ignoring the MAC address field.
Plug A name can be edited manually.
*NOTE: this name is shown on the Master Charge Point screen
Plug B name can be edited manually.
*NOTE: this name is shown on the Master Charge Point screen
Description
