Twinax Interface

Twinax jumper configuration

The following is a list of jumpers resident on the coax and twinax cards.
Jumper
J5-1 to J5-2
J7-1 to J7-2
J7-2 to J7-3
J8-1 to J8-2
J9-1 to J9-2
J9-2 to J9-3
J10-1 to J10-2
J10-2 to J10-3
J10-2 to J10-4
J11-1 to J11-2
J11-2 to J11-3
J16-1 to J16-2
J16-2 to J16-3
Twinax defaults
J5-1 to J5-2
J7-2 to J7-3
J9-1 to J9-2 (hardwired, no jumper required)
J10-1 to J10-2
J11-1 to J11-2 (hardwired, no jumper required)
J16-1 to J16-2 (hardwired, no jumper required)
38
Function
Processor clock enable
Personality select, coax I/O
Personality select, twinax I/O
Bypass capacitor for coax cable
8K processor SRAM select
32K processor SRAM select
Host select, 4400
Host select, test
Host select, 3000A
8K I/O processor data SRAM select
32K I/O processor data SRAM select
8K I/O processor CODE SRAM select
32K I/O processor CODE SRAM select
