T
Twinax Interface

Setting up twinax communications

To run your printer with the twinax interface installed, you need to do the
following:
• Set the twinax address.
• Enable IBM language translation.
• Select a character set.
• Understand characters set limitations.

Setting the twinax address

This section shows you how to set the rear panel switches to change the twinax
interface device address. The only tool necessary is a miniature flat-tip
screwdriver (Intermec Part No. 523298).
The twinax device address is set by switches 5, 6, and 7. You can set the twinax
interface address to one of seven numbers from 0 to 6. The twinax interface is
shipped from the factory with the address set at zero. To select another address,
determine which address is not used by another twinax device and then set the
switches for that address as shown in the figure on the following page. For the
changes to take effect, switch the printer power off and then on.
9
