Twinax interface self-test

Use the twinax interface self-test to determine whether the twinax interface has
been installed correctly or whether it is faulty. To run the twinax interface self-
test, complete the following procedure:
1. Turn the printer off and disconnect the twinax interface cable.
2. Set switches 5 through 7 to the ON position and set switches 1 through 4 to
Twinax interface self-test switch settings
3. Turn the printer on.
28
the OFF position. Refer to the following figure for an illustration of the
switch settings.
E
LIN
ON
UL T
FA
O
I
O
E
ON LIN
UL T
FA
O
I
ON
OFF
TWIN-08
