Ship speed indication

When the ship speed data with NMEA 0183 format is
applied, the radar can display the ship speed. Knots
(KT) or kilometres/hour (KM/h) are automatically se-
lected in the normal screen (p. 00) by selecting nauti-
cal miles (NM) or kilometres (KM) respectively.
q Push [MENU] to call up the [INT.SETTING] menu.
w Push
until "DIST UNIT" section becomes
highlighted.
e Push
to turn the ship speed indication to
] ]
NM or KM.
r Push [MENU] to exit the menu display.

Position indication

When latitude/longitude data with NMEA 0183 format
is applied, the radar can display the latitude and longi-
tude of your ship's or cursor position in the bottom of
the display. (To display the "CURSOR" position, bear-
ing data is necessary.) (P. 38)
q Push [MENU] twice to call up the "FUNCTION"
menu.
w Push
until "DATA DISP" section becomes high-
]
lighted.
e Push
to select SHIP (ship position) or
] ]
CURS (cursor position).
r Push [MENU] several times to exit the menu.

Waypoint indication

When waypoint data received from navigation equip-
ment with NMEA 0183 format is applied, the radar can
display the waypoint. To display the waypoint marker,
bearing data is necessary. (p. 38)
q Push [MENU] twice to call up the "FUNCTION"
menu.
w Push
until the "DATA DISP" section becomes
]
highlighted.
e Push
to select WPT (Waypoint).
] ]
r Push [MENU] twice to exit the menu display.

Long pulse function

To magnify the blips for easier viewing of small targets,
the long pulse and echo stretch (p. 11) functions are
available. When the long pulse is used in the
NM range, this function magnifies target echoes to the
backward direction of the target.
• Pulse selection
q Push [ADJ] to call up the Adjust menu. (p. 6)
w Push
until the "PULSE" section becomes
] ]
highlighted.
e Push
to select the long pulse.
]/ ]
r Push [ADJ] to exit the menu.
NOTE: Turn ON the SP (Short Pulse) function dur-
ing normal operation. This function reduces the tar-
get distance resolution. (p. 6).

Bearing setting

The radar bearing interface accepts NMEA, N+1 or
AUX data format and the bearing can be used as a
magnetic or true north type. When a true north type
bearing is used, the variation from magnetic north, etc.,
can be adjusted on 0.1˚ steps.
• Setting the bearing type
q Push [MENU] twice to call up "EPA" menu.
w Push
]
[INT. SETTING] menu.
e Push
until the "BRG" section becomes high-
]
lighted.
r Push
to select magnetic or true north type.
] ]
• All displayed bearing readouts show the selected bear-
ing type.
• Setting the magnetic variation
q Push
until the "MAG VAR" section becomes
]
highlighted.
w Push
an "AUTO*" or "MANU." vari-
] ]
ation.
e When a "MANU." variation is selected, push
, then push
]
ation.
r Push [MENU] to exit the menu display or push
once to proceed to the bearing input setting.
*NOTE: NMEA data is required for auto variation. NEVER
select "AUTO" variation without NMEA data. Incorrect varia-
tion data may entered. (p. 38)
4
BASIC OPERATION
3
/ to 2
4
to call up the
]
to set the bearing vari-
]
]
15
