Safety
2
Start M2 – version with standard frame (region-specific version)
1 Back support, back support upholstery
2 Side panel with forearm support
3 Seat cushion
4 Wheel lock (here: knee lever wheel lock)
5 Leg support, segmented, removable
6 Caster fork
7 Caster wheel
4 Safety
4.1 Explanation of warning symbols
Warning regarding possible serious risks of accident or injury.
WARNING
Warning regarding possible risks of accident or injury.
CAUTION
Warning regarding possible technical damage.
NOTICE
8
8 Release button for quick-release axle
9 Drive wheel adapter
10 Frame
11 Handrim
12 Drive wheel
13 Push handle
Start M2S, Start M2
