Symantec NetBackup 5000 Routine Maintenance page 23

BackupStore 5000
Routine Maintenance
Location
module
Mainboard
Rear panel
a: A location command is sent from the management system.
Issue 01 (2010-03-26)
Indicator
indicator
Fan running/alarm
indicator
Link indicator of the
management network
port
Active indicator of the
management network
port
Link indicator of the
service network port
Active indicator of the
service network port
Symantec Corporation
3 Guide to the On-Site Routine Maintenance of the
Color Status
Green Blinking
Orange On
- Off
Green On
Red On
Green On
- Off
Yellow Blinking
- Off
Green On
Orange On
- Off
Yellow Blinking
- Off
Device
Description
The AC power is
normal but the device is
not powered on.
An alarm is generated
on the power module.
The power module is
not powered on.
The fan is running
properly.
An alarm is generated
on the fan.
The link of the
management network
port is normal.
No link.
Data is being
transmitted.
No data is being
transmitted.
The speed of the data
transmission between
the NetBackup 5000
and the AS is 1000
Mbit/s.
The speed of the data
transmission between
the NetBackup 5000
and the AS is 100
Mbit/s.
The speed of the data
transmission between
the NetBackup 5000
and the AS is 10 Mbit/s
or no link.
Data is being
transmitted.
No data is being
transmitted.
3-5
