Procedure
Step 1 Check whether the strong electricity cables and the weak electricity cables are laid out on the
two sides of the cabinet, that is, the service cables and power cables are separate.
Step 2 Check whether the layout of power supply cables and service cables are tidy and orderly, and
their styles are the same as those of cables inside other cabinets in the equipment room.
Step 3 Check whether the font on the label is clear, the mark is definite and accurate, and labels are
tightly pasted on cables.
Step 4 Check whether empty slots are covered with filler panels.
Step 5 Check whether the power cables are plugged into the power sockets firmly.
Step 6 Check whether the network cables of the device are connected firmly.
Step 7 Check whether the grounding cable of the chassis is properly fastened to the cabling clip of
the chassis and the grounding terminal of the cabinet.
Step 8 Check whether the power cables are properly connected to the power sockets of the PEMs in
two groups (in redundancy).
Issue 01 (2010-03-26)
Check Item
Power cables
Service cables
Labels on cables
Handling of empty
slots
Plugs of power cables
Plugs of signal cables
Grounding cables
Power cables
Service network port
connection
Serial port connection
Symantec Corporation
3 Guide to the On-Site Routine Maintenance of the
Description
The layout of power cables should be orderly. It should
be in the same style as that of cables in other cabinets in
the equipment room.
The layout of service cables should be orderly. It should
be in the same style as that of cables in other cabinets in
the equipment room.
The font on a label should be clear, definite and
accurate. Labels should be tightly pasted on cables.
The empty slots should be covered with filler panels.
Ensure that the plug of the NetBackup 5000 power
cables are tightly inserted into the power supply socket.
Ensure that the network cables of the NetBackup 5000
are connected properly.
Ensure that the grounding cable of the chassis is
properly fastened to the cabling clip of the chassis and
the grounding terminal of the cabinet.
Connect the Power Entry Modules (PEM) of the
NetBackup 5000 with two groups (in redundancy) of
power cables properly.
Ensure that the service network cables are connected to
the service network ports and host ports/switch properly.
Ensure that the serial port is not connected to a switch.
Device
