Symantec NetBackup 5200 Quick Installation Manual

NetBackup 5200 Release 1.1
Quick Installation Guide
Revision: 01
Date: 2010-08-30
Environment Check Before Installation
You can install the NetBackup 5200 appliance in a standard 19-inch cabinet (with an AC distribution box) or any
other AC cabinet with a minimum depth of 1,000 mm. Before you install the appliance into the cabinet, do the
following:
•Reserve a space of at least 100 cm between the cabinet and the wall and the space of at least 120 cm between
cabinets for the convenience of maintenance, ventilation, and heat dissipation.
•Ensure ventilation is adequate in the cabinet and the machine room. It is recommended to reserve the space of
1U (1U = 44.45 mm = 11.4 in) above and below any device.
•Make sure that the cabinet is already installed and grounded.
Before installation, check whether the external environmental conditions, such as the power supply and heat
dissipation, satisfy the following operating requirements of the device:
•AC voltage range: 100 V to 127 V or 200 V to 240 V
•Maximum AC power of the NetBackup 5200: 700 W
•Operating temperature: 5 °C to 35 °C (altitude: - 60 m to +1,800 m)
The ambient temperature falls by 0.6 °C for every 100 m increase of the height (altitude: 1,800 m to 3,000 m)
•Operating altitude: ≤ 3,000 m
•Relative humidity: 10% RH to 85% RH
Installation Flow
Before You Start
Installing
Page 2
Page 3 Take antistatic measures
Install the NetBackup 5200 in
Page 4-6
Page 7
Page 8-9 Power on the NetBackup 5200
1
Start
Material lists
the cabinet
Connect cables
End
