Chapter 2: Jumpers and Connectors

Internal Connectors

EC Download Pin Header

Connector type: 1x3 3-pin header, 1.0mm pitch
Connector location: J10
3 1
Pin Definition
1 EC_SMB_CLK
3 GND
5 CHASSIS_GND
Copyright © 2017 NEXCOM International Co., Ltd. All Rights Reserved.
Pin Definition
2 EC_SMB_DATA
MH1 CHASSIS_GND

Debug Port

Connector type: 1x10 10-pin header, 1.0mm pitch
Connector location: J9
10
Pin Definition
1 VCC3
3 LPC_LAD0
5 LPC_LAD2
7 LPC_FRAME#
9 PLTRST_3P3#
MH1 GND
19
1
Pin Definition
2 VCC3
4 LPC_LAD1
6 LPC_LAD3
8 LPC_CLK1_DEBUG
10 GND
MH2 GND
(M)PPC-080T-BT-01 and (M)PPC-120T-BT-01/02 User Manual
