2. Installation
See section 6.1 for information on sizing protection devices and cables (Appendix, Technical data).
A maximum of four cables may be used per phase.
Upsilon STS 400 to 600 A
N
Upsilon STS 400 to 600 A
N
Page 14 -
34020113EN/AA
All manuals and user guides at all-guides.com
Input:
Output: 3 phases + PEN
L1 L2 L3 N L1 L2 L3 N
N
S1
PEN PEN
Input:
Output: 3 phases + PE + Neutral
L1 L2 L3 N L1 L2 L3 N
N
N
S1
PEN PE
3 phases + PEN
L1 L2 L3
463
mm
403
S2
mm
PEN
3 phases + PEN
L1 L2 L3
463
mm
403
S2
mm
PEN
See section 1.3 for information on accessing
the connections.
Connections are made using lugs connected
to two threaded studs per phase (diameter
10 mm).
The cables are tied to the earth bar.
See section 1.3 for information on accessing
the connections.
Connections are made using lugs connected
to two threaded studs per phase (diameter
10 mm).
The cables are tied to the earth bar.
