Outriggers - Manitowoc Grove GRT655 Operator's Manual

LUBRICATION AND MAINTENANCE
Lube Point
Item
Description

Outriggers

60 Wear Pads
61 Outrigger Beams
Jack Cylinder
62
Support Tubes
NOTE: Brush lubricant on inside diameter of jack cylinder support tubes and wear bands before installing jack cylinders.
62
9030-10
6-22
Figure Approved
No. Lubricant
Figure 6-
L
10
Figure 6-
L
10
Figure 6-
L
10
61 61
61
60
Published 3-23-2020, Control # 654-04
GRT655/655L OPERATOR MANUAL
Lube
Lube Interval
Capacity
--- 50 hours or 1 week
--- 50 hours or 1 week
Apply grease at tear-
---
down.
61
61
Application
• Brush on
• 16 places
Brush on outrigger
beam contact points
4 places
60
61
FIGURE 6-10
