SET-UP AND INSTALLATION
5-14
Upper Boom Nose
Sheaves
8993-12
5 Parts Line - 4 Sheave Hook Block
Upper Boom Nose
Sheaves
8993-11
6 Parts Line - 4 Sheave Hook Block
Published 3-23-2020, Control # 654-04
GRT655/655L OPERATOR MANUAL
To Main Hoist
Lower Boom
Nose Sheaves
Hook Block
Dead End
Hook Block
Sheaves
To Main Hoist
Lower Boom
Nose Sheaves
Boom Nose
Dead End
Hook Block
Sheaves
FIGURE 5-15 continued
