Manitowoc Grove GRT655 Operator's Manual page 146

OPERATING PROCEDURES
1
4
6
10
16
22
3
9219
Item
1 Menu Screen Indicator
2 Status Indicator Bar
3 Active Screen Indicator
4 Outrigger Group Icon
5 Outrigger Extend/Retract Icon
6 Camera Group Icon
7 Camera View 1 Icon
8 Camera View 2 Icon
9 Camera View 1/2 Icon
10 Working Range Limiter (WRL) Group Icon
11 WRL Boom Height Limit Icon
12 WRL Boom Angle Limit Icon
13 WRL Radius Limit Icon
14 WRL Swing Angle Limit Icon
4-54
5
7 8
11 12
17 18
23 24
Description
Published 3-23-2020, Control # 654-04
GRT655/655L OPERATOR MANUAL
9
13 14
20
19
26
25
Item Description
15 WRL Virtual Wall Limit Icon
16 Tools Group Icon
17 Display Screen Brightness Icon
18 Units of Measure Icon
19 Controller Sensitivity Icon
20 Controller Function Speed Icon
21 ECO Mode Icon
22 Information Group Icon
23 Operating Hours Icon
24 Engine Fault Code Icon
25 Crane Fault Code Icon
26 Software Revision Icon
27 Legal Notice Icon
2
15
21
27
FIGURE 4-21
