Outriggers - Manitowoc Grove RT540E Operator's Manual

LUBRICATION
Lube Point
Item
Description

Outriggers

Outrigger Beams
18
(Outside)
Jack Cylinder
19
Support Tubes
Jack Cylinder
51
Barrels
Outrigger Beams
54
(Inside)
5-14
Figure Approved
No. Lubricant
EP-MPG
Extreme
Pressure
Figure 5-5
Multipurpose
Grease
6829003477
EP-MPG
Extreme
Pressure
Figure 5-5
Multipurpose
Grease
6829003477
EP-MPG
Extreme
Pressure
Figure 5-5
Multipurpose
Grease
6829003477
EP-MPG
Extreme
Pressure
Figure 5-5
Multipurpose
Grease
6829003477
Published 01-15-2016, Control # 526-01
RT540E OPERATOR MANUAL
Lube
Lube Interval
Capacity
--- 50 hours or 1 week
--- 50 hours or 1 week
--- 50 hours or 1 week
--- 50 hours or 1 week
Application
Brush lubricant on
bottom of outrigger
beams
Brush lubricant on
OD of jack cylinder
barrel and wear
band before
installing jack
cylinders
Brush lubricant on
OD of jack cylinder
support tubes (4)
places before
installing jack
cylinders
Brush lubricant on
inside bottom of
outrigger beams
where beam
extension cylinder
guide supports
travel
