5.5
Battery installation
Insert the battery pack from the tail of the carrier onto the rail. Push it to the front until you hear it snap into place in
the battery pack lock.
Please make sure the battery pack is locked to prevent the battery from becoming detached while riding.
DEALER MAnuAL Max Drive SySteM
BAttERy (Bt C01.690)
battery pack lock
A
battery
b
42
