open the connector box and get ready to link female connectors with male connectors.
Push the lower part of each of the male buckles on the connector box body (in the direction as show by the arrows in
the picture above) to release the female buckles on the upper cover. Push the upper cover in the direction of moving
towards Buckle 3 to fully open the upper cover.
DEALER MAnuAL Max Drive SySteM
SyStEM InStALLAtIon
upper cover of the
A
connector box
connector box body
b
