Fix the keypad onto the handlebar with a screw. then tighten the fixing screw with an internal hex wrench.
tightening torque: 1 nm
Match the female connector at the display with the male connector at the EB-BuS as shown in the picture above.
DEALER MAnuAL Max Drive SySteM
SyStEM InStALLAtIon
2,5
mm
hex socket head cap
b
screw M3×8
female connector at the
H
display
male connector at the
h
EB-BuS
