如图所示布置速度传感器和磁体, 将磁体卡入辐条上。 
用一字头螺丝刀拧紧安装螺丝。锁紧力矩: 1.5-2  Nm
15
  速度传感器
a
  磁体螺栓
B
 
(PS01010702/
 
2308040000001)
  辐条
C
  磁体螺母 
D
(PS01010701/ 
2327000000003)
Max
驱动系统使用手册   
