按照图示打开接线盒准备接线。按照图示箭头方向按压接线盒本体上 1, 2 号卡扣的公扣下方使上
盖的母扣脱开, 然后将上盖沿着卡扣 3 的方向推上盖使上盖完全打开。
   Max
驱动系统使用手册
系统安装
  接线盒上盖 
a
  接线盒本体
B
18
