Install the chain wheel.
Chain Line: 48 mm
Preferably 36 / 38 t
Applicable to a city bike, which is equipped with an internal gearshift system and a full chain guard.
DEALER MAnuAL Max Drive SySteM
CHAIn GuARD InStALLAtIon
bushing
D
chain wheel
e
1325020000001
32
