BAFANG MAX Drive System Dealer's Manual page 58

7.2.2 Motor Cover accessories
Name
Motor cover
Cable gatherer
cross head screw assembly M3×8
7.2.3 Chain Guard assembly Module
Name
Full chain guard binder plate
P-shaped chain guard holder
M4 cross recessed pan head screw
7.2.4 Chain Wheel Module
Name
Chain wheel Module A
Chain wheel Module B (optional)
Chain wheel Module C (optional)
7.2.5 Crank Components
Name
Right straight crank with a cover
Right straight crank (optional)
Left straight crank
Crank mounting screws
57
Material No. Quantity
1333000000001 1
1401150100005 2
1401020000127 2
Material No. Quantity
1401150100004 1
1401220200003 1
1401020000111
Material No. Quantity
1325020000001
1325020000002
1325020000003
Material No. Quantity
1327040000001 1
1327010000001 1
1327020000001 1
1401020000109 2
DEALER MAnuAL Max Drive SySteM
Specification
M3×8
Specification
M4×8
Specification
CL-49 mm/38 t
CL-45 mm/38 t
CL-48 mm/38 t
Specification
170 mm
170 mm
170 mm
M8
