the picture above shows how the drive unit looks after cabling.
Please note that all cables must thread through the cable clips after going out of the connector box.
Push the buckle on the drive unit cover into the slot on the frame adapter.
DEALER MAnuAL Max Drive SySteM
SyStEM InStALLAtIon
frame adapter
A
drive unit cover
b
