系统安装
Figure 3
Figure 4
如图所示为安装完驱动单元罩壳后示例。刹车线, 变速线可选择从驱动单元底部线槽中穿过, 如图 
3 带有压线板, 也可选择从连接界面内腔中穿过, 如图4无压线板。
   Max
驱动系统使用手册
22
