如图所示为接线后示例。注意将所有线缆分路穿过线卡。
将驱动单元罩壳上部的卡扣卡入车架连接界面中的卡槽。
   Max
驱动系统使用手册
系统安装
  连接界面 
a
  电机罩壳 
B
1333000000001
