Product Information
Front Panel Components

Internal Storage Devices

The J6000 workstations support the following internal storage devices, which are also
located on the front panel, under the bezel:
• Up to two hot-pluggable, Low-Voltage Differential (LVD) hard disk drives
• One ATAPI (IDE) Slim-Line CD drive (optional)
The following subsections describe these internal storage devices.
Hard Disk Drive(s)
The J6000 workstations can support up to two hot-pluggable, Low-Voltage Differential
(LVD) hard disk drives. These hard disk drives are 3.5-inch form factor, 10K RPM devices
which connect to Ultra2 Wide LVD (Low Voltage Differential) SCSI interfaces on the disk
bay backplane. The hard disk drive bays are located on the lower left side of the front
panel, below the CD ROM drive. See Figure 1-1.
The two hard disk drive models currently supported are:
• 18 GB LVD 10K RPM disk drive (Product Number A4998A)
• 36 GB LVD 10K RPM disk drive (Product Number A6013A)
NOTE The ability to hot plug the hard disk drive(s) requires MirrorDisk/UX
(Product Number B5403BA on HP-UX 10.20, or B2491BA on HP-UX 11.0
ACE 9911).
16 Chapter 1
