Front Panel Components

Front Panel Components
Before powering on your system, you should become familiar with the system unit
controls.
Figure 1-1 shows the front panel components with the bezel attached.
Figure 1-1. System Unit Front Panel Controls With Bezel
CD ROM Bay
Hard Drive Bays
Figure 1-2. System Unit Front Panel Controls With Bezel Removed
CD Drive
Hard Disk Drive Bay Areas
CAUTION This workstation
approximately 36 to 49 pounds (16 to 22 kg), depending on the configuration.
Do not attempt to lift it by yourself, or injury may result.

Power Switch

This switch turns the system on and off. When you turn your workstation off, the operating
system automatically executes the shutdown -q command. This prevents any damage to
programs and data on your system disk. Turning the power switch back on again
automatically boots up the HP-UX operating system if your system has been configured to
auto boot.
14
System LCD
Power Switch
Locking Screw
is designated for
Captive Thumbscrew
System LCD
two-person lifting. It weighs
Chapter 1
