Figure 4-12. Removing the System Board
3
- Remove two mounting screws from
system board.
Mounting
Screws
- Pull system board toward front of workstation to remove from slots
5
- Lift system board up
Chapter 4
4
- Remove four serial port screws
from back of workstation.
Front
Field Replaceable Units (FRUs)
FRU Removal and Replacement
Back
serial port screws
Slots
97
