I/O Cards - HP Visualize j6000 Supplementary Manual

Configuration
Field Replaceable Unit (FRU) Configurations

I/O Cards

The three I/O slots located in the PCI cage area of the J6000 workstations are 64-bit, 4x,
3.3v, 66 MHz PCI (Peripheral Connect Interface) slots, providing I/O expansion
capabilities for the J6000 workstations.
CAUTION The J6000 workstations supply about 75 Watts of power to the PCI slots. Do
not insert I/O cards that together draw more than 75 Watts, or damage to the
workstation may result. Please look at the specifications that come with your
individual I/O cards for power requirements. Note that each PCI slot can
provide up to 25 watts.
34 Chapter 2
